DB15 Female PCB Mount Right Angle Connector
$ 0.26
- DB15 Female PCB Mount Right Angle ConnectorThe DB15 Female PCB Mount Right Angle Connector is a durable and precision-engineered D-Sub type connector used for reliable electrical and signal connections in various electronic and industrial systems. It features 15 female sockets arranged in a two-row D-sub configuration, designed for direct mounting onto a printed circuit board (PCB).With its right-angle (90°) orientation, this connector allows space-efficient wiring by enabling connections parallel to the board surface. The nickel-plated metal shell provides superior EMI/RFI shielding, ensuring stable data transmission and protection from electrical noise.Click here to view the related productsFeaturesDB15 (15-pin female) connector with right-angle PCB mount designReliable gold-plated contacts for excellent conductivity and corrosion resistanceNickel-plated metal shell for enhanced durability and EMI shieldingThrough-hole mounting ensures strong mechanical stability on PCBCompact, low-profile design ideal for tight or space-limited enclosuresFully compatible with DB15 male connectors, VGA, and RS-232 interfacesSpecifications :Connector Type: DB-15 FemaleMaterial: Metal and PlasticMounting Type: Right Angle PCB MountConnector: MaleVoltage Rating: 250 VACCurrent Rating: 5 AInsulation Resistance: 1000 M?Contact Resistance: 20 m?Operating Temperature Range: -55 ~ 125°CApplicationsVGA and video signal connectionsSerial communication (RS-232/RS-422) interfacesEmbedded systems and microcontroller boardsIndustrial control and instrumentation equipmentData acquisition and testing instruments*Product image for illustration purposes only, actual product may vary.
